Magic Mini 50 – where enchantment meets excellence in pool temperature control. Crafted with advanced specifications for superior performance, this mini heater chiller is your key to a magical aquatic experience.
Precision Temperature Mastery
With a heating range from 10°C to 40°C and a cooling range from 8°C to 28°C, the Magic Mini 50 ensures your pool or spa is precisely at your preferred temperature. Operating seamlessly in temperatures ranging from -25°C to 43°C, it defies the chill, making it ideal for colder climates.
Versatile Heating Capabilities
The Magic Mini 50 offers a variable max heating output ranging from 2.38 kW to 5.28 kW, providing flexibility tailored to your specific needs. Its cooling prowess ranges from 2.05 kW to 3.18 kW, ensuring a comfortable aquatic environment in any weather.
Efficient Power Consumption
Operating on a 240V power supply at 50Hz, the Magic Mini 50 ensures a balance of power and efficiency. With a variable max power input of 1.2 kW and max amps at 5.3 A, it adapts to your pool's requirements, promising optimal performance.
Quiet Magic in Every Season
Despite its power, the Magic Mini 50 maintains a sound rating of just 55 dB(A) at 1m, creating a serene oasis where the focus is on the gentle lapping of perfectly controlled water.
Eco-Conscious Excellence
Operating with eco-friendly R32 refrigerant and boasting a COP ranging from 4.58 to 7.69 and EER from 3.38 to 5.15, the Magic Mini 50 balances power, efficiency, and sustainability.
Unleash the magic in your pool with the Magic Mini 50 – where enchantment meets precision. Order now and transform your aquatic experience!
SIZING CHILLER SELECTION TABLE FOR PLUNGE POOLS (ICE BATH)
Please use this table as a reference when choosing the right-sized chiller for your plunge pool.
| Plunge Pool Size | 8°C Water Temp | 10°C Water Temp | 12°C Water Temp | 15°C Water Temp |
|---|---|---|---|---|
| < 500 L | Mini 50 (1.3 kW) | Mini 30 (1.1 kW) | Mini 30 (0.9 kW) | Mini 30 (0.6 kW) |
| 1,000 L | Mini 50 (1.4 kW) | Mini 50 (1.2 kW) | Mini 30 (1.0 kW) | Mini 30 (0.7 kW) |
| 1,500 L | Mini 50 i (1.7 kW) | Mini 50 (1.5 kW) | Mini 50 (1.2 kW) | Mini 30 (0.9 kW) |
| 2,000 L | Mini 60 i (1.9 kW) | Mini 50 i (1.7 kW) | Mini 50 (1.4 kW) | Mini 30 (1.1 kW) |
| 2,500 L | HC 0704 (2.2 kW) | Mini 60 i (1.9 kW) | Mini 50 (1.7 kW) | Mini 50 (1.3 kW) |
| 3,000 L | HC 0704 (2.4 kW) | HC 0704 (2.2 kW) | Mini 50 i (1.9 kW) | Mini 50 (1.5 kW) |
| 4,000 L | HC 1005 (2.9 kW) | HC 0704 (2.6 kW) | Mini 60 i (2.3 kW) | Mini 50 (1.9 kW) |
| 5,000 L | HC 1005 (3.4 kW) | HC 1005 (3.1 kW) | HC 0704 (2.8 kW) | Mini 50 i (2.3 kW) |
| 6,000 L | HC 1307 (3.9 kW) | HC 1005 (3.6 kW) | HC 1005 (3.2 kW) | Mini 60 i (2.6 kW) |
Estimate Chiller load Assumptions for a Domestic Plunge pool.
Location, ambient temperature, Pool temperature, indoor pools, outdoor pools, pool covers, heated rooms, high-use periods and chiller operating hours will all change the heat load of a plunge pool. The above guide is just that a guide. The above guide is based on a 2-person user plunge pool. Commercial pools or pools with high usage should always seek a sizing estimate. The estimate above is also a minimum suggested size.
The above Sizing Chiller Selection Table is based on 28 C Ambient, Indoor Plunge Pool, No Cover, 12-hour chiller operating hours and 2-person pool usage.
It is highly recommended to select the next unit up when pool kW demands are at the edge of a selected unit’s nominal kW cooling capacity.
| Model | Cooling (KW) | HP | Litres of Water | Power |
|---|---|---|---|---|
| Mini 30 | 1.5 | 0.4 | < 1,000 | 1 Phase |
| Mini 50 | 2.6 | 1.0 | 1,500 | 1 Phase |
| Magic Mini 50 i (Inverter) | 3.0 | 1.2 | 2,000 | 1 Phase |
| Magic Mini 60 i (Inverter) | 3.3 | 1.3 | 2,500 | 1 Phase |
| Platypus HC 0704-1 | 2.68 | 1.6 | < 4,000 | 1 Phase |
| Platypus HC 1005-1 | 4.02 | 2.0 | 5,000 | 1 Phase |
| Platypus HC 1307-1 | 5.36 | 2.5 | 6,000 | 1 Phase |
| Platypus HC 1709-1 | 5.82 | 3.0 | 7,000 | 1 Phase |
| Platypus HC 2111-1 | 6.96 | 4.0 | 8,000 | 1 Phase |
| Platypus HC 3015-1 | 9.52 | 5.7 | 10,000 | 1 Phase |
| Platypus HC 3015-3 | 9.92 | 5.7 | 12,500 | 3 Phase |
| Platypus HC 3520-3 | 12.07 | 7.5 | 15,000 | 3 Phase |
Specifications
| Heating Range | 10°C to 40°C |
| Cooling Range | 8°C to 28°C |
| Operating Range | -25°C to 43°C |
| Max Heating Output | 2.38 to 5.28 kW |
| Max Cooling Output | 2.05 to 3.18 kW |
| Air 15°C & Water 26°C | |
| Capacity | 2.05 to 4.15 kW |
| Input | 0.27 to 0.91 kW |
| Amps | 1.19 to 3.98 A |
| COP | 4.58 to 7.69 |
| Air 35°C & Water 27°C | |
| Capacity | 2.05 to 3.18 kW |
| Input | 0.40 to 0.94 kW |
| Amps | 1.74 to 4.09 A |
| EER | 3.38 to 5.15 |
| Power Supply | 240 V 50Hz |
| Max Power Input | 1.2 kW |
| Max Amps | 5.3 A |
| Water Connections | 32/38 mm |
| Water Flow | 2.3 m3/Hr |
| Pressure Drop | 20 kPa |
| Refrigerant | R32 |
| Pressure minimax | 1.5/4.3 MPa |
| Sound Rating 1m | 55 dB(A) |
| Water Proof Rating | IPX4 |
| Weight | 32 kg |
In The Box
- [1] x Toyesi Platypus Magic Mini 50 - Compact Heater / Chiller Heat Pumps | 8°C to 38°C
- Experience high efficiency and eco-friendliness with our R32 refrigerant.
- Achieve heating COP ranging from 4.0 to 13.8 and cooling EER between 2.7 to 5.1.
- Choose from three variants: Mini 30, Mini 50, and Magic Mini 50, all featuring EVI and Inverter technologies.
- The Magic Mini 50 is specially designed for cold climate areas.
- Enjoy a temperature output range of 8 °C to 43 °C for versatile use.
- Benefit from an ergonomically compact design with a robust ABS plastic casing and anti-UV protection.
- Lightweight at 26 to 32kg, making it suitable for small aquatic projects.
- Easy installation with a 32/38mm water connection, offering a plug-and-play solution.
- Get fantastic value for money with our reliable refrigerant system.
Q: What is the Magic Mini 50 designed for?
A: The Magic Mini 50 is designed to provide superior temperature control for pools and spas, especially excelling in colder climates with its operating range extending down to -25°C.
Q: Can the Magic Mini 50 be used for both heating and cooling purposes?
A: Absolutely. The Magic Mini 50 is a versatile mini heater chiller, offering both heating and cooling capabilities to ensure your pool or spa is at the perfect temperature, regardless of the weather.
Q: How does the variable max heating output benefit users?
A: The Magic Mini 50 offers a variable max heating output ranging from 2.38 kW to 5.28 kW, providing users with flexibility to tailor the heating capacity according to their specific needs and preferences.
Q: Is the Magic Mini 50 energy-efficient?
A: Yes, it is. Operating with eco-friendly R32 refrigerant and featuring a COP ranging from 4.58 to 7.69, the Magic Mini 50 is designed for efficient power consumption, balancing performance with environmental sustainability.
