Luxx Lighting LED Grow Light Bar - 200W | 80R | 80% Red | Dimmable | 124CM

Power cable is required to be purchased separately

SKU: LEDL80301

Luxx Lighting Co.

Luxx Lighting LED Grow Light Bar - 200W | 80R | 80% Red | Dimmable | 124CM

Products You May Need

(ACES91021) Luxx Lighting LED Bar Bracket Only - For Luxx 200W & 300W Bars - In Stock

$74.95

(ACES91022) Luxx Lighting LED Bar 15A Cable Only - For Luxx 200W & 300W Bars - In Stock

$79.95

Qty:

Pick up at store Not Available

In-store pickup not available.

Delivery Charge: Free

International shipping

Click here

SECURE PAYMENTS WITH

BUY NOW, PAY LATER

Pay in 4, interest-free. Afterpay it.

ZIP NOW, PAY LATER

Repay on a convenient weekly, fortnightly or monthly schedule.

ENJOY NOW, PAY LATER

The Luxx 200W LED Bar is designed and built using top quality components including top bin diodes that produce a plant loving Veg Spectrum. The 200w LED Bar form factor is adaptive to any cultivation environment by being able to select your wattage and footprint. The 200w LED Bars can be run in single stacked, multi-stacked, or a greenhouse grow setting. The modular design allows you to customize and scale up your 200w LED Bar system to fit your operation needs.

The 80R spectrum provides a full spectrum with maximum red photon content. The blue-green balance supports healthy plant morphology and enables an improved working environment and improved visual inspection for growers.

Specifications

Size: 1240MM (length) x 60MM (Width) x 72MM (Height)
Weight: 3.26KG
Input Power: 200W
Min Power Factor: >0.95
Rated Mains Voltage: 200V - 277V
Voltage Range: 200V - 305V
Mains Frequency: 50/60Hz
THD: <10%
Thermal Management: Passive
Dimming:
- 40% to 100% - EXT/OFF
- If using our NX-1, it only dims down to 50%.

In The Box

[1] x Luxx Lighting LED Grow Bar - 200W | 80R | 80% Red | Full Spectrum

10ft 240V (HGC906341) and 277V (HGC906342) cords, connectors, and splitters SOLD SEPARATELY
1 bar
ETL Listed
Modular design
Mounts to Unistrut
Bar bracket (HGC906320) SOLD SEPARATELY, strongly recommended to provide a fully modular fixture to fit both 4’ and 5’ footprints. One kit includes two brackets.
Configure a 200W, 400W, 600W, 800W, or 1000W
Available in 80% red or 90% red
All in one design
Plug & Play
5-year warranty

INSTALLATION WARNING!

READ THE FOLLOWING INSTRUCTIONS CAREFULLY BEFORE USING OR WORKING WITH THE 200W LED BAR.

The 200w LED Bar contains a glass lens over the LEDs. Please handle it with care.
Always gently place the 200w LED Bar on a clean, soft surface to avoid damaging the glass.
In order to mount your 200w LED Bar properly, start by identifying a suitable support structure in which you can mount your 200w LED bar.
Common support structures include pallet racks, trusses, structural channels, Unistrut, and rolling tables. • The user is responsible for correct and safe installation and usage.
Please have two or more experienced, certified service personnel mount and install this device, in accordance with the applicable local laws and regulations.
The best practice is to have a licensed electrician install your 200w LED Bar.
Ensure the existing electrical system can support the voltage and current requirements of the 200w LED Bar.
When daisy chaining the 200w LED Bars together, make sure that you’re not attempting to connect more than the maximum amount of 200w LED Bars based on the voltage that your power cable and electrical system are rated for. Read the product specifications to see the maximum amount of 200w LED Bars that can be daisy-chained together.
